Overview      Pneumatics    Valves    Valve terminals
Valve terminal G1/8, 24VDC, 4 stations, Multi-pin, S1R kopen

Valve terminal G1/8", 24VDC, 4 stations, Multi-pin, S1R



€ 167,55 Exclusive of VAT View volume discount
€ 202,74 Inclusive of VAT

  Shipped today
  From € 7,90

Valve terminal G1/8, 24VDC, 4 stations, Multi-pin, S1R kopen
Valve terminal G1/8", 24VDC, 4 stations, Multi-pin, S1R
  Shipped today Own warehouse, stock on demand possible. Personal advice
   In cart


Product information
|
Downloads
|
Specifications
|
Combinations
|
Accessories

Product information
Valve terminal with 4 stations, G1/8", 24VDC, Multi-pin connection.

Downloads
  PN20412 (.STEP)
Specifications
Article number
PN20412
Article code
S1R-1/8-4
Port connection
G1/8
Working pressure (bar)
1.5-8
Max. pressure (bar)
12
Operating voltage
24VDC
Voltage tolerance
±10%
Switching time (at 5 bar)
<50 ms, max. 5 circuits/sec
Protection class
IP40
Operating temperature (°C)
-5 tot +60
Body material
Aluminium
Sealing material
NBR
Number of stations
4
Consumption
2,8W / station
Flow per station (L/min)
500 l/min


Combinations
This product has no combinations (yet).

Accessories

5/2 valve, monostable, G1/8", 24VDC, RV10
€ 35,50
excl. VAT
View volume discount
  Shipped today

5/2 valve, monostable, G1/4", 24VDC, RV20
€ 32,70
excl. VAT
View volume discount
  Shipped today
