Valve terminal G1/8", 24VDC, 7 stations, Multi-pin, S1R

Name: Valve terminal G1/8, 24VDC, 7 stations, Multi-pin, S1R
SKU: PN20415
Price: 269.4 EUR
Availability: InStock
Rating: 4 (12 reviews)

€ 269,40 Exclusive of VAT View volume discount
€ 325,97 Inclusive of VAT

In stock

In stock Own warehouse, stock on demand possible. Personal advice

In cart

Product information

Downloads

Specifications

Combinations

Accessories

Product information

Valve terminal with 7 stations, G1/8", 24VDC, Multi-pin connection.

Downloads

PN20415 (.STEP)

Specifications

Article number	PN20415
Article code	S1R-1/8-7
Port connection	G1/8
Working pressure (bar)	1.5-8
Max. pressure (bar)	12
Operating voltage	24VDC
Voltage tolerance	±10%
Switching time (at 5 bar)	<50 ms, max. 5 circuits/sec
Protection class	IP40
Operating temperature (°C)	-5 tot +60
Body material	Aluminium
Sealing material	NBR
Number of stations	7
Consumption	2,8W / station
Flow per station (L/min)	500 l/min

Alle maten en soorten

Number

Description

Stock

Unit price

Quantity

PN20412

Valve terminal G1/8", 24VDC, 4 stations, Multi-pin, S1R
Consumption: 2,8W / station
Port connection: G1/8
Operating voltage: 24VDC Stock:

In stock

€ 167,55

PN20413

Valve terminal G1/8", 24VDC, 5 stations, Multi-pin, S1R
Consumption: 2,8W / station
Port connection: G1/8
Operating voltage: 24VDC Stock:

In stock

€ 201,42

PN20414

Valve terminal G1/8", 24VDC, 6 stations, Multi-pin, S1R
Consumption: 2,8W / station
Port connection: G1/8
Operating voltage: 24VDC Stock:

In stock

€ 235,74

PN20415

Valve terminal G1/8", 24VDC, 7 stations, Multi-pin, S1R
Consumption: 2,8W / station
Port connection: G1/8
Operating voltage: 24VDC Stock:

In stock

€ 269,40

PN20416

Valve terminal G1/8", 24VDC, 8 stations, Multi-pin, S1R
Consumption: 2,8W / station
Port connection: G1/8
Operating voltage: 24VDC Stock:

In stock

€ 302,85

PN20417

Valve terminal G1/4", 24VDC, 6 stations, Multi-pin, S2R
Consumption: 3,0W / station
Port connection: G1/4
Operating voltage: 24VDC Stock:

In stock

€ 234,71

Show all products

Combinations

This product has no combinations (yet).

Accessories

This product has no accessories (yet).
